Name: Refrigeration Expansion Valve EEV EXV for Mini Split Systems 12VDC
Brand: Ningbo Brando Hardware Co., Ltd
SKU: EEV
Price: 65.00 USD
Availability: InStock

Casa Prodotti Elettrovalvola a solenoide di refrigerazione

Refrigeration Expansion Valve EEV EXV for Mini Split Systems 12VDC

Dettagli:

Luogo di origine:	Cina
Marca:	BRANDO
Certificazione:	None
Numero di modello:	EEV

Termini di pagamento e spedizione:

Quantità di ordine minimo:	5 pezzi
Prezzo:	Negoziabile
Imballaggi particolari:	Scatola interna, cartone, pallet
Tempi di consegna:	Negoziazione
Termini di pagamento:	T/T, Western Union, MoneyGram
Capacità di alimentazione:	100000 pezzi al mese

Contatto

Descrizione di prodotto dettagliata

Nome del prodotto:	Valvola elettronica di espansione	Dimensione della porta:	6.35mm OD, 7.94mm OD
Dimensione dell'orifizio:	0,6 - 4.5mm	Capacità di raffreddamento:	0,7 - 67,7 chilowatt (per R22)
Refrigerante applicabile:	R22, R410A, R407C, R32, R134A, R404A, R507C, ecc	Pressione operativa massima:	43 barre
Max Operating Pressure Differential:	35 barre	Tensione nominale:	12VDC (±10%), onda rettangolare
Evidenziare:	EEV Electronic Expansion Valve 12v , EXV Electronic Expansion Valve 12vdc , Electronic Expansion Valve EEV EXV

Refrigeration Expansion Valve EEV EXV for Mini Split Systems 12VDC

Electronic Expansion Valves (EEV, EXV) are designed for use in air conditioning and refrigeration systems or in heat pumps. The valve controls the automatic adjustment of refrigerant flow rate and makes the system work under optimized conditions for the purpose of fast cooling or heating, precise temperature control and energy saving. The valve can also be used e.g. for suction line pressure controls. These valves provide bidirectional operation to control the refrigerant flow rate in heating or cooling mode.

Specifications:

Applicable Refrigerants	R22, R410A, R407C, R32, R134A, R404A, R507C, etc
Medium Temperature	-30 to +70℃
Ambient Temperature	-30 to +60℃
Relative Humidity	0 to 95% RH
Coil Voltage	12VDC (±10%), rectangular wave
Coil Current	260mA/phase (20°C)
Coil Resistance	46±3.7 Ω/phase (20°C)
Coil Insulation Class	E
Coil Protection Class	IP67
Excitation Mode	1 to 2 phase excitation, monopole actuation
Excitation Rate	30pps to 90pps
Activation of self-holding mechanism	Maintain excitation in stop position min. 0.1 to 1 sec
Min. motion time from completely open to completely closed	5.8s (90pps)

Technical Data:

Model No	Nominal Cooling Capacity (kW)					Kv (m³/h)	MOP (bar)	MOPD (bar)	ROP (bar)
Model No	R22	R407C	R410A	R32	R134A	Kv (m³/h)	MOP (bar)	MOPD (bar)	ROP (bar)
EEV0.6A	0.7	0.7	0.8	1.2	0.5	0.01	43	35	≥25
EEV0.8A	1.2	1.3	1.4	2.1	0.9	0.017
EEV1.0A	2.7	2.8	3.1	4.6	2.1	0.025
EEV1.3A	5.3	5.7	6.2	9.2	4.2	0.05
EEV1.6A	9.0	9.5	10.5	15.5	7.0	0.08
EEV1.8A	10.6	11.3	12.5	18.4	8.3	0.1
EEV2.0A	13.2	14.0	15.4	22.8	10.3	0.16
EEV2.2A	14.2	15.1	16.6	24.5	11.1	0.2
EEV2.4A	16.7	17.7	19.5	28.8	13.0	0.23
EEV3.0A	27.6	29.4	32.3	47.7	21.6	0.39			≥15
EEV3.2A	30.4	32.4	35.6	52.6	23.8	0.43			≥15
EEV4.0B	50.6	53.8	59.2	87.5	39.5	0.5			≥7
EEV4.5B	67.7	72.0	79.2	117.0	52.9	0.7			≥7

Main Dimension:

Refrigeration Expansion Valve EEV EXV for Mini Split Systems 12VDC 0

Model No	Orifice Size (mm)	Dimension (mm)
		F	G	H	φd	φN
EEV0.6A	0.6	80	36	30	6.35	17.35
EEV0.8A	0.8
EEV1.0A	1.0
EEV1.3A	1.3
EEV1.6A	1.6
EEV1.8A	1.8
EEV2.0A	2.0
EEV2.2A	2.2
EEV2.4A	2.4
EEV3.0A	3.0	83	39	39	7.94
EEV3.2A	3.2
EEV4.0B	4.0	101	47	51
EEV4.5B	4.5

Production Show:

Refrigeration Expansion Valve EEV EXV for Mini Split Systems 12VDC 1
