Name: 1-1/4'' PTFE Anti Corrosion Solenoid Valve for Acid Alkali Chemical
Brand: Ningbo Brando Hardware Co., Ltd
SKU: 6.16DAP32B32
Price: 25.00 USD
Availability: InStock

Casa Prodotti Elettrovalvola a solenoide di plastica

1-1/4'' PTFE Anti Corrosion Solenoid Valve for Acid Alkali Chemical

Dettagli:

Luogo di origine:	NINGBO, CINA
Marca:	BRANDO
Certificazione:	None
Numero di modello:	6.16DAP32B32

Termini di pagamento e spedizione:

Quantità di ordine minimo:	200
Prezzo:	Negoziabile
Imballaggi particolari:	scatole interne, cartoni, pallet
Tempi di consegna:	Negoziazione
Termini di pagamento:	T/T,Paypal,Western Union
Capacità di alimentazione:	100000 pezzi al mese

Contatto

Descrizione di prodotto dettagliata

Funzione:	Modo 2, normalmente chiuso	Dimensione della porta:	1-1/4''
Dimensione dell'orifizio:	32 mm	Materiale del corpo valvola:	PTFE
Materiale della guarnizione:	EPDM, FKM, PTFE	Intervallo di pressione di esercizio:	0da 0,01 a 0,6 MPa
Tensioni:	12VDC, 24 VDC, 110VAC, 220VAC	Operazione:	Pilota Operated del pistone
Mezzo di lavoro:	Prodotti chimici, acidi, alcali, liquidi corrosivi, ecc.
Evidenziare:	PTFE Solenoid Valve 1-1/4'' , Anti Corrosion Solenoid Valve 1-1/4'' , Anti Corrosion Solenoid Valve 110v

1-1/4'' PTFE Anti Corrosion Solenoid Valve for Acid Alkali Chemical

This is an anti corrosive PTFE solenoid valve, 1-1/4'' female threaded port size, 32mm orifice size, 2/2 way normally closed, pilot piston operated, 0.01 to 0.6 MPa working pressure, can be EPDM, FKM or PTFE seal to suit different working mediums, various voltages for your choice, such as 12VDC, 24VDC, 24VAC, 110VAC and 220VAC, etc. It is used for a wide arrange of industrial applications to control fluids.

Technical Data:

Model No	Port Size	Orifice Size	CV	Working Pressure	Body Material	Seal Material	Function	Voltage
6.16DAP15B04	1/2''	15mm	4	0 to 6 bar	PTFE	EPDM FKM PTFE	2 Way NC	12VDC 24VDC 24VAC 110VAC 220VAC
6.16DAP20B06	3/4''	20mm	5.5
6.16DAP25B25	1''	25mm	13
6.16DAP32B32	1-1/4''	32mm	17
6.16DAP40B40	1-1/2''	40mm	25
6.16DAP50B50	2''	50mm	40
6.16DAP65B65	2-1/2''	60mm	62

Main Dimension:

Model No	Dimension
Model No	P	D	H	E	A	M	L	K	F
6.16DAP15B04	1/2''	70	127	56.5	18.5	M5	14	92	58
6.16DAP20B06	3/4''	80	136	70.5	20	M6	10	92	67
6.16DAP25B25	1''	95	145	78	25	M6	12	92	75
6.16DAP32B32	1-1/4''	120	200	110	31	M8	20	94	98
6.16DAP40B40	1-1/2''	130	220	113	33.5	M8	18	94	106
6.16DAP50B50	2''	150	249	140	43	M10	20	94	116
6.16DAP65B65	2-1/2''	180	262	152	49	M10	25	94	116

Our Production:

1-1/4'' PTFE Anti Corrosion Solenoid Valve for Acid Alkali Chemical 1

FAQ:

Question 1: What is a solenoid valve used for?
Answer 1: A solenoid valve is used to open, close, mix, or divert media in an application. They are used in a wide variety of applications.

Question 2: How can you tell if your solenoid valve is bad?
Answer 2: If the solenoid valve fails to open or close, is partially open, makes a humming noise or has a burned-out solenoid coil, you need to troubleshoot the valve solenoids.

Question 3: How do I choose a solenoid valve?
Answer 3: When choosing a solenoid valve, it is important to know your media. Depending upon the media and flow requirement, choose the material, port size, orifice size, temperature, pressure, voltage, response time and certification required for your application.
