Casa ProdottiElettrovalvola a solenoide dell'acciaio inossidabile

2S050-15 1/2'' Airtac Type Solenoid Valve Stainless Steel 304 220V 110V 24V

2S050-15 1/2'' Airtac Type Solenoid Valve Stainless Steel 304 220V 110V 24V

  • 2S050-15 1/2'' Airtac Type Solenoid Valve Stainless Steel 304 220V 110V 24V
2S050-15 1/2'' Airtac Type Solenoid Valve Stainless Steel 304 220V 110V 24V
Dettagli:
Luogo di origine: Ningbo, Cina
Marca: BRANDO
Certificazione: None
Numero di modello: 2S050-15
Termini di pagamento e spedizione:
Quantità di ordine minimo: 100 pezzi
Prezzo: Negoziabile
Imballaggi particolari: Scatola, cartone, pallet
Tempi di consegna: Negoziazione
Termini di pagamento: T/T, PayPal, Western Union
Capacità di alimentazione: 100000 pcs al mese
Contatto
Descrizione di prodotto dettagliata
Nome del prodotto: Valvola solenoide Dimensione della porta: 1/2»
dimensione dell' orificio: 5 mm Materiale del corpo: Acciaio inossidabile 304
Materiale di sigillo: NBR (norma), EPDM, FKM (facoltativo) Medio di lavoro: Acqua, aria, gas, liquido, ecc
Funzione: Modo 2 normalmente chiuso Azione: Ad azione diretta
Pressione di esercizio: da 0 a 10 bar tensione: 220VAC, 110VAC, 24VAC, 24VDC, 12VDC
Evidenziare:

Airtac Solenoid Valve 2S050-15

,

Stainless Steel Water Solenoid Valve

,

Solenoid Valve Stainless Steel 1/2''

2S050-15 Airtac Type Stainless Steel Solenoid Valve



Product Features:
1. Working Medium: Water, Air, Gas, Liquid, etc
2. Max Working Pressure: 10 bar
3. Medium Temperature: NBR (-5 to +80ºC), EPDM (-5 to +120ºC), FKM (-10 to +150ºC)
4. Port Size: 1/8'', 1/4'', 3/8'', 1/2'', 3/4'', 1''
5. Orifice Size: 3mm, 5mm, 15mm, 20mm, 25mm
6. Body Material: Stainless Steel 304
7. Seal Material: NBR (Standard), EPDM, FKM
8. Operation: Direct Acting (DN3 to DN5), Pilot Operated (DN15 to DN25)
9. Function: 2 Way Normally Closed
10. Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)

Technical Data:
Model No 2S030-06 2S030-08 2S050-10 2S050-15 2S150-10 2S150-15 2S200-20 2S250-25
Port Size 1/8'' 1/4'' 3/8'' 1/2'' 3/8'' 1/2'' 3/4'' 1''
Orifice Size 3mm 3mm 5mm 5mm 15mm 15mm 20mm 25mm
CV 0.33 0.33 0.83 0.83 5.5 5.5 9.5 12.5
Body Material Stainless Steel 304
Seal Material NBR (Standard), EPDM, FKM
Working Medium Water, Air, Gas, Liquid, etc
Working Temperature
NBR: -5 to +80℃
EPDM: -5 to +120℃
FKM: -10 to +150℃
Working Pressure 0 to 10 bar 0.5 to 10 bar
Operation Direct Acting Pilot Operated
Function 2 Way Normally Closed
Supply Voltage 12VDC, 24VDC, 24VAC, 110VAC, 220VAC

Main Dimension:
2S050-15 1/2'' Airtac Type Solenoid Valve Stainless Steel 304 220V 110V 24V 0
Model No Port A B C D L
2S030-06 1/8'' 60 25 70 41 16
2S030-08 1/4'' 60 25 70 41 16
2S050-10 3/8'' 72 31 85 52 23
2S050-15 1/2'' 72 31 85 52 23
2S150-10 3/8'' 92 46 105 70 /
2S150-15 1/2'' 92 46 105 70 /
2S200-20 3/4'' 96 53 113 82 /
2S250-25 1'' 102 59 122 92 /



Our Production:

2S050-15 1/2'' Airtac Type Solenoid Valve Stainless Steel 304 220V 110V 24V 1



More Solenoid Valves:

2S050-15 1/2'' Airtac Type Solenoid Valve Stainless Steel 304 220V 110V 24V 2
2S050-15 1/2'' Airtac Type Solenoid Valve Stainless Steel 304 220V 110V 24V 3
2S050-15 1/2'' Airtac Type Solenoid Valve Stainless Steel 304 220V 110V 24V 4
2S050-15 1/2'' Airtac Type Solenoid Valve Stainless Steel 304 220V 110V 24V 5



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
