2 Way Latching Brass Solenoid Valve For Water Air 6VDC 12VDC 24VDC
Product Features of Latching Brass Solenoid Valve:
1. Working Medium: Air, Water, etc.
2. Working Pressure Range: 0 to 1.2 MPa (See the parameter table below for details)
3. Medium Temperature Range: NBR (-10 to +80℃), EPDM (-30 to +120℃), FKM (-30 to +150℃)
4. Port Size: 1/8'', 1/4'', 3/8''
5. Orifice Size: 1.6mm, 2.5mm, 3.0mm, 4.0mm, 5.0mm, 6.0mm
6. Body Material: Brass, Stainless Steel
7. Seal Material: NBR, EPDM, FKM
8. Operation: Direct Acting
8. Latching Coil Voltage Option: 6VDC, 12VDC, 24VDC, Instant power-on time (0.3 to 0.5 sec)
Technical Data of Latching Brass Solenoid Valve:
Model
Port Size
Orifice Size
Cv
Min Pressure
Max Pressure
Seal Material
Body Material
DC
12BA161
1/8''
1.6mm
0.11
0MPa
1.2MPa
NBR
EPDM
FKM
Brass
Stainless Steel
12BA251
1/8''
2.5mm
0.18
1.2MPa
12BA301
1/8''
3.0mm
0.3
0.8MPa
12BA252
1/4''
2.5mm
0.18
1.0MPa
12BA302
1/4''
3.0mm
0.3
0.8MPa
12BA402
1/4''
4.0mm
0.5
0.4MPa
12BA403
3/8''
4.0mm
0.5
0.4MPa
12BA503
3/8''
5.0mm
0.71
0.3MPa
12BA603
3/8''
6.0mm
0.78
0.2MPa
