2L-20 3/4'' Brass Solenoid Valve For Steam And Hot Water 12V 24V 110V 220V
Product Features of 2L series Steam Solenoid Valve:
1. Working Medium: Hot Water, Steam, etc
2. Working Pressure Range: 0.1 to 1.5 MPa
3. Seal Material: PTFE
4. Body Material: Brass, Stainless Steel
5. Port Size: 3/8'', 1/2'', 3/4'', 1'', 1 1/4'', 1 1/2'', 2''
6. Orifice Size: 17mm, 22mm, 30mm, 50mm
7. Operation: Piston Pilot Operated
8. Function: 2 Way Normally Closed
9. Coil Voltage Option: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)
Technical Data of 2L series Steam Solenoid Valve:
|
2L Series Model
|
|
|
|
|
|
|
|
|
US Series Model
|
|
|
|
|
|
|
|
|
Orifice Size
|
|
|
|
|
|
|
|
|
Port Size
|
|
|
|
|
|
|
|
|
Medium
|
|
|
Action
|
|
|
Function
|
|
|
Body Material
|
|
|
Seal Material
|
|
|
|
|
|
Temp. Range
|
|
|
Coil Voltages
|
12VDC, 24VDC, 24VAC, 110VAC, 220VAC
|
Dimension of 2L series Steam Solenoid Valve:
