Luogo di origine: | La CINA |
Marca: | Brando |
Certificazione: | CE |
Numero di modello: | BB14542505 |
Quantità di ordine minimo: | 1 insieme |
---|---|
Prezzo: | negotiation |
Imballaggi particolari: | Scatola interna, cartone, pallet |
Tempi di consegna: | 4-8 giorni |
Termini di pagamento: | L/C, T/T, Western Union, Paypal, MoneyGram |
Capacità di alimentazione: | 500000 messi al mese |
Tipo: | 0545 tipo di 110-030 NASS | Materiale: | Resina Thermoset, rame |
---|---|---|---|
Nome di prodotto: | 0545 tipo sistema 13 di 110-030 NASS della bobina dell'elettrovalvola a solenoide | Tensione: | AC220V AC110V/DC12V DC24V (±10%) |
Dimensione del foro: | 14,6 millimetri | TEMPERATURA AMBIENTE: | - 20 °C ~ + °C 50 |
Applicazione: | Elettrovalvola a solenoide dell'acqua e valvola di scarico elettronica | Classe d'isolamento: | F, H |
Tipo di collegamento: | DIN43650A | Grado di protezione con il connettore: | IP 65 (IP 67 a richiesta) |
Evidenziare: | 113-030-0142 0545 Coil,113-030-0141 0545 Coil,Nass Type Magnet 230VAC |
230V AC 113-030-0142 113-030-0141 113-030-0138 Auto Drain Valve 0545 Coil
Everyone knows that solenoid valves play an important role in industrial applications, and they have a long running time, and sometimes there are some problems that make the equipment not function properly. Most of this problem is caused by improper use of the solenoid valve coil.
The solenoid valve coil may not be very secure at the time of installation. During the operation of the device, the coil is in a strong operation, so that the coil will fall, the solenoid valve will not operate normally, or some may fall, and some may not. It may cause the device to work for a while and not work properly, both of which will delay the work. At this time, the operation is relatively simple, and the coil can be firmly fixed on the solenoid valve. There is also a case where the solenoid valve coil may be burnt out due to excessive voltage, and the device may not operate normally.
Technical parameter of 0545 110-030 NASS Type Solenoid Valve Coil:
Code No | Voltages | Frequency(Hz) |
Power (W)
|
Power (VA) |
113-030-0123 | 24vDC | 4,1 | ||
113-030-0144 | 24VAC | 50 | 8,8 | |
113-030-0144 | 24VAC | 60 | 7,6 | |
113-030-0128 | 220VAC | 50 | 9,0 | |
113-030-0128 | 240VAC | 60 | 9,2 | |
113-030-0142 | 230VAC | 50 | 8,8 | |
113-030-0142 | 230VAC | 60 | 7,6 | |
113-030-0121 | 220VAC | 50 | 14,0 | |
113-030-0124 | 24VDC | - | 7,9 | |
113-030-0135 | 24VAC | 50 | 14,0 | |
113-030-0135 | 24VAC | 60 | 12,0 | |
113-030-0279 | 110 VAC | 50 | 13,9 | |
113-030-0279 | 110VAC | 60 | 12,2 | |
113-030-0125 | 24VDC | - | 11,9 | |
113-030-0129 | 24VAC | 50 | 21,0 | |
113-030-0129 | 24VAC | 60 | 18,0 | |
113-030-0126 | 110VAC | 50 | 21,5 | |
113-030-0141 | 230 VAC | 50 | 22,0 | |
113-030-0141 | 230VAC | 60 | 19,0 | |
113-030-0120 | 12VDC | - | 17,5 | |
113-030-0127 | 24VAC | 50 | 25,0 | |
113-030-0132 | 24VDC | - | 18,5 | |
113-030-0120 | 36VAC | 50 | 25,0 | |
113-030-0137 | 110VAC | 50 | 27,5 | |
113-030-0140 | 110VAC | 60 | 26,5 | |
113-030-0137 | 120VAC | 60 | 28,0 | |
113-030-0133 | 220VAC | 50 | 25,5 | |
113-030-0122 | 220VAC | 50 | 22,0 | |
113-030-0138 | 230VAC | 50 | 25,5 | |
113-030-0133 | 240VAC | 60 | 25,0 | |
113-030-0138 | 240VAC | 60 | 27,0 |
Main dimension of Nass Type 0545 Electronic Drain Solenoid Coils:
Phyical map of 113-030-0028 nass type electromagnetic coil:
Applicatoin of nass type 113-030-0035 electric magnetic coil:
More details about 0545 110-030 series Solenoid Coil can be found below the Youtube Video:
Product Features:
1. Using high quality wire which has UL approved; 2. Using high quality permeablity magnetic material which contain low carbon;
3. Using high quality housing material like PA66, PBT, PPS, BMC and so on.
4. Insulation class can be B, F, H, N, C;
5. Protection class can be IP65, IP67 & IP69K;
6. We also offer special coils like ex-proof coils, water proof coils and so on.
7. If you have special requirement, pls feel free to contact us.
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
